Adaptor furtun tata (conic) - 3040

Adaptor furtun tata (conic)

Maximum pressure 1/8 - 150 bar; 1/4 - 100bar; 3/8-75 bar; 1/2-50 bar; 3/4-85 bar; 1-80 bar
Fluids Compressed air, water, оils, fluids for hydraulics and pneumatics
Temperature range +300° C

Nr. Articol	Preț (buc.)	Cantitate (buc)	A	A1	B	C	L	CH
0703040000	8,39 lei		6	1/8	19.5	7.5	32	12
0703040002	8,39 lei		6	1/4	19.6	11	35.5	14
0703040004	8,39 lei		7	1/8	19.7	7.5	32	12
0703040006	8,39 lei		7	1/4	19.8	11	35.5	14
0703040008	8,39 lei		8	1/8	19.9	7.5	32	12
0703040010	8,39 lei		8	1/4	19.10	11	35.5	14
0703040012	8,39 lei		9	1/8	19.11	7.5	32	12
0703040014	8,39 lei		9	1/4	19.12	11	35.5	14
0703040016	10,02 lei		9	3/8	19.13	11.5	36	17
0703040018	13,43 lei		9	1/2	19.14	14	39	22
0703040020	8,39 lei		10	1/8	19.15	7.5	32	112
0703040022	8,39 lei		10	1/4	19.16	11	35.5	14
0703040024	10,02 lei		10	1/8	19.17	11.5	36	17
0703040026	13,43 lei		10	1/2	19.18	14	39	22
0703040028	10,02 lei		12	1/4	19.19	11	35.5	14
0703040030	10,02 lei		12	3/8	19.20	11.5	36	17
0703040032	15,07 lei		12	1/2	19.21	14	39	22
**********	-	-	14	3/8	19.22	11.5	36	17
**********	-	-	14	1/2	19.23	14	39	22
**********	-	-	16	3/8	19.24	11.5	36	17
**********	-	-	16	1/2	19.25	14	39	22
**********	-	-	16	3/4	19.26	16.5	43.5	27
**********	-	-	17	3/8	19.27	11.5	36	18
**********	-	-	17	1/2	19.28	14	39	22
**********	-	-	18	3/8	19.29	11.5	36	19
**********	-	-	18	1/2	19.30	14	39	22
**********	-	-	18	3/4	19.31	16.5	43.5	27
**********	-	-	20	3/8	30	11.5	36	21
**********	-	-	20	1/2	30	14	49.5	22
**********	-	-	20	3/4	30	13.5	50.5	27
**********	-	-	25	3/4	30	14.5	51.5	27
**********	-	-	25	1''	30	16	53.5	34
