DexyFlex®
KBN2 U2
KBN2 U2
Descripton: stainless steel hose, parallel corrugations, single-wall, heavy wall thickness, standard pitch
Design: Corrugated hose with two braidings
Hose material: Austenitic, stainless steel (DIN 17441); DN 6 up to 50 - AISI 316L; DN 65 up to 100 - similiar to AISI 321; DN 150 up to 300 - similiar to AISI 316 Ti; Other materials available on request.
Braiding material: Austenitic, stainless steel (DIN 17440). Similiar to AISI 304; Other materials available on request.
Temperature range: usable from -270°C to +600°C
Required specification for ordering:
* Type of hose ( KBN2 U2 )
* Hose material
* Nominal diameter ( DN )
* Total lenght ( GL )
* Number of braidings ( U2 )
* End fittings ( Type and material )
* Working pressure
* Working temperature
Attention: Please follow reduction factors for the permissible pressure and bending radius at increased temperature and dynamic stress from the catalogue sheet " Design of metal hoses"
| Article No. | Price (per meter) | Quantity (meters) | DN[mm / inch] | Type | Internal diameter d1 [mm] | Internal diameter Tol.+/- [mm] | External diameter d2 [mm] | External diameter d3 [mm] | External diameter Tol.+/- [mm] | Bending radius single motion Rst [mm] | Bending radius several motion Rb [mm] | Working pressure at 20°C Pmax [bar] | Weight (+/- 10%) [kg/m] |
| ********** | - | - | 6 mm / 1/4" | KBN2 U2 | 5,8 | 0,2 | - | 13,5 | 0,4 | 40 | 150 | 400 | 0,42 |
| ********** | - | - | 8 mm / 5/16" | KBN2 U2 | 7,5 | 0,2 | - | 15,8 | 0,4 | 50 | 180 | 380 | 0,46 |
| ********** | - | - | 10 mm / 3/8" | KBN2 U2 | 10,3 | 0,3 | - | 16,9 | 0,5 | 60 | 220 | 300 | 0,63 |
| ********** | - | - | 12 mm / 1/2" | KBN2 U2 | 12 | 0,3 | - | 20,4 | 0,5 | 70 | 250 | 315 | 0,84 |
| ********** | - | - | 16 mm / 5/8" | KBN2 U2 | 16,2 | 0,3 | - | 25,8 | 0,5 | 90 | 195 | 280 | 1,03 |
| ********** | - | - | 20 mm / 4/5" | KBN2 U2 | 20,3 | 0,3 | - | 30,6 | 0,5 | 70 | 285 | 165 | 1,22 |
| ********** | - | - | 25 mm / 1" | KBN2 U2 | 25,4 | 0,3 | - | 36,3 | 0,6 | 85 | 325 | 135 | 1,45 |
| ********** | - | - | 32 mm / 1 1/4" | KBN2 U2 | 34,3 | 0,3 | - | 45 | 0,6 | 105 | 380 | 100 | 1,98 |
| ********** | - | - | 40 mm / 1 4/7" | KBN2 U2 | 40 | 0,4 | - | 54 | 0,6 | 130 | 430 | 75 | 2,67 |
| ********** | - | - | 50 mm / 2" | KBN2 U2 | 50,2 | 0,4 | - | 64,4 | 0,7 | 160 | 490 | 45 | 3,29 |
| ********** | - | - | 65 mm / 2 5/8" | KBN2 U2 | 64,7 | 0,4 | - | 87,2 | 0,7 | 200 | 580 | 45 | 5,22 |
| ********** | - | - | 80 mm / 3 1/8" | KBN2 U2 | 79,6 | 0,5 | - | 104,2 | 0,8 | 240 | 720 | 33,75 | 6,36 |
| ********** | - | - | 100 mm / 3 16/17" | KBN2 U2 | 99,7 | 0,5 | - | 132,6 | 0,8 | 290 | 900 | 30 | 10,07 |
| ********** | - | - | 125 mm / 4 11/12" | KBN2 U2 | 124,4 | 0,6 | - | 160,1 | 0,9 | 350 | 1125 | 27,75 | 12,17 |
| ********** | - | - | 150 mm / 5 10/11" | KBN2 U2 | 150,0 | 0,7 | - | 188,1 | 1 | 400 | 1550 | 27,75 | 15.98 |
| ********** | - | - | 200 mm / 7 6/7" | KBN2 U2 | 200,3 | 0,8 | - | 242,1 | 1.1 | 520 | 2000 | 18,75 | 19.87 |
| ********** | - | - | 250 mm / 9 5/6" | KBN2 U2 | 250,0 | 0,8 | - | 294,6 | 1.1 | 620 | 2500 | 14,25 | 25.84 |
| ********** | - | - | 300 mm / 11 4/5" | KBN2 U2 | 300,0 | 1,0 | - | 347,0 | 1.3 | 720 | 3000 | 9,75 | 27.92 |
