Clamps DIN2817 / Aluminium

Clamps DIN2817 / Aluminium

Working pressure: -0,8 bar up to 25 bar

Temperature range: 20^oC to + 65^oC; House, coupling and assembly method must be chosen in relation with the desired application and temperature range.

Characteristics: It is produced in three variants - from aluminium, brass or stainless steel. Assembly of the rbber hoses used in food, pharmaceutical and transport industry applications. Safety clamps are used to assemble EN/DIN standardized hoses and couplings with a smoot hose shank complying with EN 14420-2 / DIN 2817. RK safety clamaps are supplied complete with nuts and bolts

Article No.	Price (pcs.)	Quantity (pcs.)	DN mm	For hose mm	External hose Ø mm	Dimensions High mm	Dimensions Width mm	Nuts and bolts Quantity	Nuts and bolts Thread metric	Weight kg/pcs
**********	-	-	15 mm / 4/7"	13 x 5	22 - 24	50	51	4	M6	0.12
2190020500	9,17 €		20 mm / 4/5"	19 x 6	30 - 33	50	63	4	M6	0.12
2190020700	9,62 €		25 mm / 1"	25 x 6	36 - 39	50	69	4	M6	0.14
2190020800	11,31 €		25 mm / 1"	25 x 8	40 - 43	50		4	M6	0.15
2190020900	9,60 €		32 mm / 1 1/4"	32 x 6	43 - 46	50	76	4	M6	0.15
2190021500	14,45 €		40 mm / 1 4/7"	38 х 8	50 -52	50	83	4	M6	0.15
2190022300	16,07 €		50 mm / 2"	50 x 8	63 - 67	56	102	4	M8	0.29
**********	-	-	50 mm / 2"	50 x 10	69 - 71	56	102	4	M8	0.33
2190022700	18,84 €		65 mm / 2 5/8"	63 x 8	78 - 82	74	120	4	M8	0.43
2190023100	39,23 €		80 mm / 3 1/8"	75 x 8	89 - 93	76	132	4	M8	0.49
**********	-	-	80 mm / 3 1/8"	75 x 10	94 - 97	76	132	4	M8	0.52
2190023700	63,99 €		100 mm / 3 15/16"	100 x 8	114 - 119	120	166	4	M10	1.09
**********	-	-	100 mm / 3 15/16"	100 x 10	118 - 122	120	166	4	M10	1.15
**********	-	-	125 mm / 4 11/12"	125 x 10	143 - 148	145	210	6	M10	1.88
**********	-	-	150 mm / 5 10/11"	150 x 10	167 - 173	180	227	6	M12	3.78
**********	-	-	200 mm / 7 6/7"	200 x 12	222 - 229	240	284	8	M12	6.52
